| Thread Diameter Size (TDZ) | 1/4″ | Special Feature | Small Shank |
| Threads per Inch (TPI) | 20 | Tool Type | Extension Tap |
| Thread Standard | NC | Chamfer | Plug |
| Overall Length (OAL) | 6″ | Coating | Uncoated |
| Thread Cutting Part Length (THL) | 1″ | Style | Plug |
| Connection Diameter Machine Side (DCONMS) | 0.185″ | Cutting Direction (HAND) | Right Hand |
| Flute Count (NOF) | 4 | Measurement Type | Inch |
| Cutting Edge Material | HSS | Series/List # | 113P |
| Thread Tolerance Class (TCTR) | H3 | Thread Size | 1/4″ - 20 |
Product Features
| Remarks | •Small Shank Extension Taps •High Speed Steel Ground Thread | Country of Origin | USA |
Shipping Info
Additional Fees and Notes
0
Package Length
5.90550
Package Width
.47240
Package Height
.39370
Package Weight
0.097
