| Cutting Diameter (DC) | 1″ | Flute Helix Angle (FHA) | CW |
| Connection Diameter Machine Side (DCONMS) | 1″ | Shank Type | Round |
| Depth of Cut Maximum (APMX) | 3″ | End Shape | Corner Radius |
| Overall Length (OAL) | 6″ | Usable Length (LU) | 3″ |
| Cutting Edge Material | Carbide | Corner Radius (RE) | 0.03″ |
| Coating | AlTiN | Grade | KC643M |
| Flute Count (NOF) | 5 | Decimal Equivalent | 1″ |
Product Features
| Remarks | •Kennametal standard dimensions. •Non-center cutting. •Unequal flute spacing minimizes chatter for smoother machining. •For finishing and semi-finishing applications. •Optimized geometry for machining corners at deep cavities. | Country of Origin | USA |
Shipping Info
Package Weight
1.0494
