| Cutting Diameter (DC) | 1/2″ | Flute Helix Angle (FHA) | CW |
| Connection Diameter Machine Side (DCONMS) | 1/2″ | Shank Type | Round |
| Depth of Cut Maximum (APMX) | 1-1/4″ | End Shape | Corner Radius |
| Overall Length (OAL) | 3″ | Usable Length (LU) | 1-1/4″ |
| Cutting Edge Material | Carbide | Corner Radius (RE) | 0.12″ |
| Coating | AlTiN | Grade | KC643M |
| Flute Count (NOF) | 5 | Decimal Equivalent | 0.5″ |
Product Features
| Remarks | •Kennametal standard dimensions. •Non-center cutting. •Ramping up to 3°. •Unequal flute spacing minimizes chatter for smoother machining. •Single tool for both roughing and finishing operations requiring fewer setups. •Optimized geometry for titanium machining. •Five-flute geometry enables slotting up to 1 x D. | Country of Origin | USA |
Shipping Info
Package Weight
.2690
